Double-End Straight UVC Germicidal Lamp T5 | Bi-Pin & Instant-Start, 4–79W

Product Overview

The double-end straight T5 UVC tube is the most widely installed germicidal lamp format in the world — the direct descendant of the fluorescent tube, with a G5 bi-pin base at each end and a quartz arc tube in between. It is the lamp inside HVAC upper-air units, coil-irradiation kits, conveyor surface sanitizers, laboratory biosafety cabinets, and exposed-tube water sterilizers on every continent. The Legia Smart GPH-T5 series covers the complete range: twelve models from 4W (135mm) to 79W (1630mm), delivering up to 250 μW/cm² of 254nm intensity at one meter with a 10,000-hour rated life.

Because these tubes are almost always purchased as replacements for installed equipment, interchangeability is engineered in, not asserted. Lamp dimensions, G5 bi-pin bases, operating currents, and UV output follow the established industry standard, so a Legia Smart tube drops into existing fixtures and ballasts without modification — including the ubiquitous TUV-type installations found in air handlers and sterilization fixtures worldwide.

For equipment that cycles frequently or must strike reliably at low temperature, the companion instant-starting series (G-T5) provides nine models from 17W to 79W built on instant-start cathode technology: the lamp ignites immediately on power-up without a preheat phase, tolerating the frequent on/off cycling that destroys preheat cathodes. Instant-start models are identified by their single-pin or colored-cap end terminals and run on standard 425mA instant-start ballasts.

Built for the Replacement Market

Every tube in the series starts as high-purity fused quartz, refined to reduce the impurity content that absorbs 254nm photons, then coated internally to suppress solarization — the gradual UV-darkening that silently erodes dose in uncoated economy tubes. The cathode is a proprietary filament design with an emitter coating formulated for long life at the standard 425mA operating point (170mA on the 4W miniature model). High initial intensity and a shallow decay curve mean the tube that goes in at service still delivers specification dose when the next annual service comes around.

Both ozone-free and 185nm ozone-generating quartz versions are available across the range: ozone-free for germicidal air and surface duty, ozone-generating where combined UV + ozone oxidation is specified for odor control, grease breakdown in kitchen exhaust, or TOC reduction.

Core Advantages

• Universal G5 Bi-Pin Format — Why It Matters: The installed base of double-end T5 germicidal fixtures is enormous and standardized. A lamp that matches the dimensional and electrical standard exactly can be sold into that base with zero revalidation risk — the definition of a replacement-market product.
• Instant-Start Models for Cycling Applications — Why It Matters: Motion-activated upper-air units, demand-controlled kitchen exhaust UV, and intermittent surface sanitizers can cycle dozens of times per day. Preheat cathodes lose emitter material on every strike; instant-start cathodes are built for exactly this duty, preserving rated life under cycling.
• 10,000-Hour Rated Life — Why It Matters: Matches the standard annual replacement interval for germicidal lamps, with output margin at end of life instead of an output deficit.
• 4W–79W in Twelve Lengths — Why It Matters: From a 135mm biosafety-cabinet tube to a 1630mm air-handler lamp, one product line covers the full replacement map — simplifying distributor inventory and OEM sourcing.
• High-Purity Coated Quartz — Why It Matters: Solarization-resistant coating and low-impurity quartz keep 254nm transmission high for the full service interval, so validated systems stay validated.
• Ozone-Free or 185nm Versions — Why It Matters: One mechanical platform serves pure germicidal duty or combined UV+ozone oxidation — selected at order time to match the process.

Typical Applications

HVAC Air Disinfection: Upper-air germicidal fixtures and in-duct coil-irradiation systems in hospitals, schools, offices, and transport hubs — the largest installed application for double-end T5 tubes.

Surface & Conveyor Sanitization: Exposed-tube UV tunnels over conveyor belts, packaging lines, and filling machines in food, beverage, and pharmaceutical production.

Laboratory & Healthcare Equipment: Biosafety cabinets, clean benches, pass-through chambers, and room sterilization fixtures using the compact 4W–21W models.

Water & Liquid Disinfection: Exposed-lamp and quartz-sleeve water sterilizers, and the germicidal light source inside Legia Smart UV disinfection cabinets.

Technical Specifications

Double-End Straight T5 — Standard Series (G5 Bi-Pin)

Model	Tube Dia (mm)	Length (mm)	Arc Length (mm)	Power (W)	Current (mA)	Voltage 50/60Hz (V)	UV Intensity @1m (μW/cm²)	UVC Output (W)	Rated Life (h)
GPH135T5L(VH)	15	135	73	4	170	28	16	1.5	10,000
GPH212T5L(VH)	15	212	150	10	425	30	22	2.0	10,000
GPH287T5L(VH)	15	287	225	14	425	41	40	4.0	10,000
GPH303T5L(VH)	15	303	241	15	425	43	42	4.1	10,000
GPH330T5L(VH)	15	330	268	17	425	44	45	4.5	10,000
GPH357T5L(VH)	15	357	295	18	425	51	54	5.7	10,000
GPH436T5L(VH)	15	436	374	21	425	62	72	7.3	10,000
GPH793T5L(VH)	15	793	731	37	303	105	90	13.0	10,000
GPH843T5L(VH)	15	843	781	41	425	120	150	15.0	10,000
GPH1148T5L(VH)	15	1148	1086	55	425	165	180	22.0	10,000
GPH1554T5L(VH)	15	1554	1492	75	425	220	240	33.0	10,000
GPH1630T5L(VH)	15	1630	1568	79	425	231	250	34.5	10,000

Instant-Starting Series (G-T5)

Model	Tube Dia (mm)	Length (mm)	Arc Length (mm)	Power (W)	Current (mA)	Voltage 50/60Hz (V)	UV Intensity @1m (μW/cm²)	UVC Output (W)	Rated Life (h)
G10T5L(VH)	15	357	277	17	425	42	54	5.7	10,000
G18T5L(VH)	15	386	306	18	425	48	59	6.0	10,000
G24T5L(VH)	15	538	458	25	425	65	82	8.0	10,000
G30T5L(VH)	15	692	612	32	425	80	95	9.8	10,000
G36T5L(VH)	15	843	763	41	425	100	130	12.5	10,000
G37T5L(VH)	15	868	768	42	425	120	133	13.0	10,000
G48T5L(VH)	15	1148	1068	55	425	135	170	18.0	10,000
G64T5L(VH)	15	1554	1474	75	425	179	220	29.0	10,000
G67T5L(VH)	15	1630	1550	79	425	189	225	31.0	10,000

UV intensity measured at 1 meter distance. Custom lamp bases, and ozone-free or ozone-generating (185nm) quartz, are available to order — contact us with your fixture or ballast specification.
